| UPC: | 722856053510 | Weight: | 35 LB |
| Packaged Length: | 45 IN | Packaged Width: | 42 IN |
| Packaged Height: | 12.4 IN |
| Output HP: | 1.50 Hp | Output KW: | 1.1 kW |
| Frequency: | 60/50 Hz | Voltage: | 230/460 V |
| Current: | 4.0/2.0 A | Speed: | 3490 rpm |
| Service Factor: | 1.15 | Phase: | 3 |
| Efficiency: | 84 % | Power Factor: | 82 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | M |
| Frame: | 56J | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6205 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 55 |
| Electrical Type: | Squirrel Cage Induction Run | Starting Method: | Across The Line |
| Poles: | 2 | Rotation: | Reversible |
| Resistance Main: | 8.5 Ohms | Mounting: | Round |
| Motor Orientation: | HORIZONTAL | Drive End Bearing: | BALL |
| Opp Drive End Bearing: | BALL | Frame Material: | Rolled Steel |
| Shaft Type: | J | Overall Length: | 12.87 in |
| Frame Length: | 6.50 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 2.56 in | Assembly/Box Mounting: | F1 ONLY |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Break-Down | 0.00 | 11.20 | 498.0 | 2,600 | 1.50 | |||
| Pull-Up | 0.00 | 8.50 | 378.0 | 200 | 1.50 | |||
| Full Load | 2.00 | 2.25 | 100.0 | 3,521 | 1.50 | |||
| Locked-Rotor | 21.00 | 8.50 | 378.0 | 0 | 1.50 |
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 125 % | 150 % |
| Current (Amps) | 1.00 | 1.14 | 1.39 | 1.69 | 2.03 | 2.44 | 2.87 |
| Rated Output (KW) | 0.10 | 0.42 | 0.72 | 1.03 | 1.33 | 1.64 | 1.98 |
| Efficiency (%) | 0.0 | 67.8 | 79.1 | 82.2 | 84.6 | 84.7 | 84.2 |
| Power Factor (%) | 12.6 | 46.2 | 64.7 | 76.3 | 82.2 | 84.6 | 86.8 |
| Speed (RPM) | 3,599 | 3,578 | 3,559 | 3,540 | 3,521 | 3,501 | 3,478 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 46.0 | 0.0 | 0.0 |
| Torque (ft-lbs) | 0.00 | 0.56 | 1.12 | 1.68 | 2.25 | 2.80 | 3.38 |
