Original price was: $2,419.00.$1,527.14Current price is: $1,527.14.
| UPC: | 691720245545 | Weight: | 48 LB |
| Packaged Length: | 0 IN | Packaged Width: | 0 IN |
| Packaged Height: | 0 IN |
| Output HP: | 1.50 Hp | Output KW: | 1.1 kW |
| Frequency: | 60/50 Hz | Voltage: | 208-230/460 V |
| Current: | 4.8-4.4/2.2 A | Speed: | 1750 rpm |
| Service Factor: | 1.15 | Phase: | 3 |
| Efficiency: | 86.5 % | Power Factor: | 73.5 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | M |
| Frame: | 145 C | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6205 | Opp Drive End Bearing Size: | 6205 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 43 |
| Electrical Type: | Squirrel Cage Inverter Rated | Starting Method: | Line Or Inverter |
| Poles: | 4 | Rotation: | Reversible |
| Resistance Main: | 0 Ohms | Mounting: | Rigid base |
| Motor Orientation: | HORIZONTAL | Drive End Bearing: | BALL |
| Opp Drive End Bearing: | BALL | Frame Material: | Stainless Steel |
| Shaft Type: | NEMA 56 | Overall Length: | 13.62 in |
| Frame Length: | 7.99 in | Shaft Diameter: | 0.875 in |
| Shaft Extension: | 2.25 in | Assembly/Box Mounting: | F1 ONLY |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Pull-Up | 19.40 | 882.0 | 15.28 | 339.0 | 257 | 9.60 | 61.9 | 1.50 |
| Full Load | 2.20 | 100.0 | 4.51 | 100.0 | 1,745 | 1.32 | 75.5 | 1.50 |
| Locked-Rotor | 19.90 | 905.0 | 18.10 | 401.0 | 0 | 9.50 | 59.5 | 1.50 |
| Break-Down | 12.50 | 568.0 | 21.05 | 467.0 | 1,286 | 8.30 | 83.3 | 1.50 |
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 115 % | 125 % | 150 % |
| Current (Amps) | 1.30 | 1.40 | 1.60 | 1.90 | 2.20 | 2.48 | 2.60 | 3.00 |
| Rated Output (KW) | 0.11 | 0.40 | 0.69 | 1.00 | 1.32 | 1.54 | 1.66 | 2.01 |
| Efficiency (%) | 0.0 | 70.5 | 79.5 | 84.1 | 84.6 | 83.8 | 84.6 | 83.5 |
| Power Factor (%) | 10.2 | 35.7 | 54.4 | 66.3 | 75.5 | 77.9 | 80.1 | 84.1 |
| Speed (RPM) | 0 | 1,785 | 1,773 | 1,759 | 1,745 | 1,735 | 1,730 | 1,713 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 53.2 | 0.0 | 0.0 | 0.0 |
| Torque (ft-lbs) | 0.00 | 1.11 | 2.19 | 3.38 | 4.51 | 5.24 | 5.71 | 6.90 |
