Original price was: $1,216.00.$812.05Current price is: $812.05.
| UPC: | 691720052525 | Weight: | 20 LB |
| Packaged Length: | 14.58 IN | Packaged Width: | 13.75 IN |
| Packaged Height: | 13.22 IN |
| Output HP: | 0.25 Hp | Output KW: | 0.19 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 2.6/1.3 A | Speed: | 1735 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Efficiency: | 59.5 % | Power Factor: | 99 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | No Design Code | KVA Code: | B |
| Frame: | 48YZ | Enclosure: | Totally Enclosed Air Over |
| Thermal Protection: | Automatic | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | N | IP Code: | 55 |
| Electrical Type: | Permanent Split Capacitor | Starting Method: | Across The Line |
| Poles: | 6 | Rotation: | Selective Clockwise |
| Resistance Main: | 22.59 Ohms | Mounting: | Round – Extended Studs |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Stainless Steel |
| Shaft Type: | Single Special Extension | Overall Length: | 11.58 in |
| Shaft Diameter: | 0.500 in | Shaft Extension: | 4.05 in |
| Assembly/Box Mounting: | F1 Only |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Pull-Up | 3.87 | 322.0 | 5.60 | 52.0 | 0 | 0.65 | 0.0 | 0.25 |
| Break-Down | 2.50 | 208.0 | 18.50 | 171.0 | 0 | 0.54 | 0.0 | 0.25 |
| Full Load | 1.20 | 100.0 | 10.80 | 100.0 | 1,744 | 0.28 | 0.0 | 0.25 |
| Locked-Rotor | 3.80 | 317.0 | 3.30 | 31.0 | 0 | 0.65 | 0.0 | 0.25 |
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 115 % | 125 % | 150 % |
| Current (Amps) | 0.64 | 0.71 | 0.90 | 1.10 | 1.20 | 1.50 | 1.60 | 2.10 |
| Rated Output (KW) | 0.15 | 0.16 | 0.21 | 0.25 | 0.28 | 0.34 | 0.37 | 0.47 |
| Efficiency (%) | 18.5 | 29.3 | 45.0 | 55.4 | 59.1 | 62.9 | 63.7 | 60.1 |
| Power Factor (%) | 99.2 | 99.2 | 99.5 | 100.0 | 102.5 | 98.6 | 100.3 | 96.5 |
| Speed (RPM) | 1,786 | 1,782 | 1,769 | 1,754 | 1,744 | 1,721 | 1,708 | 1,643 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| Torque (ft-lbs) | 1.70 | 3.00 | 5.90 | 9.00 | 10.80 | 14.00 | 15.50 | 19.20 |
