Original price was: $1,301.00.$868.23Current price is: $868.23.
| UPC: | 691720052563 | Weight: | 24 LB |
| Packaged Length: | 14.58 IN | Packaged Width: | 13.75 IN |
| Packaged Height: | 13.22 IN |
| Output HP: | 0.50 Hp | Output KW: | 0.37 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 5.2/2.6 A | Speed: | 1750 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Efficiency: | 72 % | Power Factor: | 97 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | No Design Code | KVA Code: | D |
| Frame: | 48YZ | Enclosure: | Totally Enclosed Air Over |
| Thermal Protection: | Automatic | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | N | IP Code: | 55 |
| Electrical Type: | Permanent Split Capacitor | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Selective Clockwise |
| Resistance Main: | 8.376 Ohms | Mounting: | Round – Extended Studs |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Stainless Steel |
| Shaft Type: | Single Special Extension | Overall Length: | 11.58 in |
| Shaft Diameter: | 0.500 in | Shaft Extension: | 4.05 in |
| Assembly/Box Mounting: | F1 Only |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Full Load | 2.60 | 100.0 | 24.40 | 100.0 | 1,736 | 0.58 | 0.0 | 0.50 |
| Locked-Rotor | 8.80 | 338.0 | 6.80 | 28.0 | 3 | 1.36 | 0.0 | 0.50 |
| Break-Down | 5.30 | 204.0 | 44.40 | 182.0 | 1,596 | 1.12 | 0.0 | 0.50 |
| Pull-Up | 7.20 | 277.0 | 5.20 | 21.0 | 102 | 1.12 | 0.0 | 0.50 |
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 115 % | 125 % | 150 % |
| Current (Amps) | 0.90 | 1.30 | 1.70 | 2.10 | 2.60 | 2.90 | 3.10 | 3.90 |
| Rated Output (KW) | 0.17 | 0.28 | 0.37 | 0.47 | 0.58 | 0.65 | 0.70 | 0.86 |
| Efficiency (%) | 0.0 | 33.3 | 50.4 | 59.9 | 64.9 | 66.3 | 66.7 | 65.2 |
| Power Factor (%) | 80.7 | 93.6 | 94.9 | 96.9 | 96.8 | 97.3 | 97.9 | 95.5 |
| Speed (RPM) | 1,795 | 1,781 | 1,769 | 1,755 | 1,736 | 1,725 | 1,715 | 1,678 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| Torque (ft-lbs) | 0.00 | 5.90 | 11.90 | 18.00 | 24.40 | 28.10 | 30.60 | 37.50 |
