Original price was: $4,843.00.$3,289.53Current price is: $3,289.53.
| UPC: | 691720052716 | Weight: | 143 LB |
| Packaged Length: | 0 IN | Packaged Width: | 0 IN |
| Packaged Height: | 0 IN |
| Output HP: | 5 Hp | Output KW: | 3.7 kW |
| Frequency: | 60/50 Hz | Voltage: | 230/460 V |
| Current: | 12.4/6.2 A | Speed: | 1745 rpm |
| Service Factor: | 1.15 | Phase: | 3 |
| Efficiency: | 89.5 % | Power Factor: | 84 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | J |
| Frame: | 184TC | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6306 | Opp Drive End Bearing Size: | 6306 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 55 |
| Electrical Type: | Squirrel Cage Inverter Rated | Starting Method: | Line Or Inverter |
| Poles: | 4 | Rotation: | Reversible |
| Resistance Main: | 2.041 Ohms | Mounting: | Rigid base |
| Motor Orientation: | HORIZONTAL | Drive End Bearing: | BALL |
| Opp Drive End Bearing: | BALL | Frame Material: | Stainless Steel |
| Shaft Type: | T | Overall Length: | 16.97 in |
| Frame Length: | 11.42 in | Shaft Diameter: | 1.125 in |
| Shaft Extension: | 2.75 in | Assembly/Box Mounting: | F1 ONLY |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Break-Down | 0.00 | 0.0 | 49.00 | 327.0 | 0 | 0.00 | 0.0 | 5.00 |
| Locked-Rotor | 46.00 | 742.0 | 32.00 | 213.0 | 0 | 0.00 | 0.0 | 5.00 |
| Pull-Up | 0.00 | 0.0 | 27.00 | 180.0 | 0 | 0.00 | 0.0 | 5.00 |
| Full Load | 6.20 | 100.0 | 15.00 | 100.0 | 1,758 | 0.00 | 0.0 | 5.00 |
