Original price was: $19,507.00.$13,904.59Current price is: $13,904.59.
| UPC: | 722856002594 | Weight: | 0 LB |
| Packaged Length: | 66 IN | Packaged Width: | 46 IN |
| Packaged Height: | 32.39 IN |
| Output HP: | 125 Hp | Output KW: | 93.0 kW |
| Frequency: | 60/50 Hz | Voltage: | 460 V |
| Current: | 140.0 A | Speed: | 1786 rpm |
| Service Factor: | 1.15 | Phase: | 3 |
| Efficiency: | 95.4 % | Power Factor: | 88 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | F |
| Frame: | 444T | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6319 | Opp Drive End Bearing Size: | 6317 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 43 |
| Electrical Type: | Squirrel Cage Inverter Rated | Starting Method: | Part Wdg Start Or Inverter |
| Poles: | 4 | Rotation: | Reversible |
| Resistance Main: | .038 Ohms | Mounting: | Rigid Base |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Cast Iron |
| Shaft Type: | T | Overall Length: | 50.79 in |
| Shaft Diameter: | 3.375 in | Shaft Extension: | 8.5 in |
| Assembly/Box Mounting: | F1/F2 CAPABLE |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Locked-Rotor | 850.00 | 610.0 | 735.00 | 200.0 | 0 | 35.0 | 125.00 | |
| No Load | 35.50 | 25.5 | 0.00 | 0.0 | 1,800 | 6.0 | 125.00 | |
| Break-Down | 500.00 | 358.0 | 1,050.00 | 285.0 | 1,750 | 74.0 | 125.00 | |
| 2/3 | 700.00 | 500.0 | 700.00 | 190.0 | 1,400 | 125.00 | ||
| Pull-Up | 775.00 | 555.0 | 650.00 | 176.0 | 1,000 | 125.00 | ||
| 1/3 | 825.00 | 590.0 | 650.00 | 176.0 | 500 | 125.00 | ||
| Full Load | 140.00 | 100.0 | 367.00 | 100.0 | 1,786 | 88.0 | 125.00 |
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 115 % | 125 % |
| Current (Amps) | 36.00 | 49.00 | 76.00 | 106.00 | 140.00 | 160.00 | 175.00 |
| Rated Output (KW) | 2.50 | 25.50 | 49.20 | 73.50 | 97.50 | 113.00 | 123.00 |
| Efficiency (%) | 0.0 | 93.0 | 95.0 | 95.4 | 95.4 | 95.0 | 94.5 |
| Power Factor (%) | 6.0 | 65.0 | 82.0 | 87.0 | 88.0 | 88.0 | 88.0 |
| Speed (RPM) | 1,800 | 1,796 | 1,794 | 1,790 | 1,786 | 1,784 | 1,782 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 55.0 | 75.0 | 90.0 |
| Torque (ft-lbs) | 0.00 | 91.50 | 183.00 | 275.00 | 367.00 | 423.00 | 460.00 |
