Description
5KCP49UN9614S – Marathon 1 HP 2 speed Condenser Fans HVAC/R Motor, 1 phase, 1200/1200 RPM, 200-230 V, 56Z Frame, ODP – P185
5KCP49UN9614S Marathon Condenser Fans Motors
Please advise CFM, static pressure, voltage, phase, and/or horsepower on specifications, drawings, or existing equipment for an accurate quote.
General Specifications
| UPC: |
722856038036 |
Weight: |
34 LB |
| Packaged Length: |
15.63 IN |
Packaged Width: |
9.88 IN |
| Packaged Height: |
7.5 IN |
Nameplate Specifications
| Output HP: |
1 Hp |
Output KW: |
0.75 kW |
| Frequency: |
60 Hz |
Voltage: |
200-230 V |
| Current: |
4.8-5.0 A |
Speed: |
1075 rpm |
| Service Factor: |
1 |
Phase: |
1 |
| Efficiency: |
67.5 % |
Power Factor: |
0 |
| Duty: |
Continous |
Insulation Class: |
B |
| KVA Code: |
B |
Frame: |
56Z |
| Enclosure: |
Drip Proof |
Thermal Protection: |
AUTO |
| Ambient Temperature: |
40 °C |
Drive End Bearing Size: |
6203 |
| Opp Drive End Bearing Size: |
6203 |
UL: |
Recognized |
| CSA: |
Yes |
CE: |
N |
Technical Specifications
| Electrical Type: |
Permanent Split Capacitor(PSC) |
Starting Method: |
N/R |
| Poles: |
6 |
Rotation: |
Counterclockwise/Clockwise |
| Mounting: |
Resilient Rings |
Motor Orientation: |
ANY |
| Drive End Bearing: |
BALL |
Opp Drive End Bearing: |
BALL |
| Frame Material: |
Rolled Steel |
Overall Length: |
14.87 in |
| Frame Length: |
6.55 in |
Shaft Diameter: |
0.63 in |
| Shaft Extension: |
6 in |
Thru-bolts Extension: |
0 in |
