Original price was: $1,152.00.$821.15Current price is: $821.15.
| UPC: | 691720000281 | Weight: | 40 LB |
| Packaged Length: | 15.16 IN | Packaged Width: | 9.65 IN |
| Packaged Height: | 10 IN |
| Output HP: | 1.50 Hp | Output KW: | 1.1 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 15.2/7.6 A | Speed: | 1725 rpm |
| Service Factor: | 1.15 | Phase: | 1 |
| Efficiency: | 75 % | Power Factor: | 80 |
| Duty: | 15 Minute | Insulation Class: | B |
| Design Code: | N | KVA Code: | K |
| Frame: | 56C | Enclosure: | Totally Enclosed Non Ventilated |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 43 |
| Electrical Type: | Capacitor Start Capacitor Run | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Selective Counterclockwise |
| Resistance Main: | 0 Ohms | Mounting: | Rigid Base |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Stainless Steel |
| Shaft Type: | NEMA 56 | Overall Length: | 12.60 in |
| Frame Length: | 7.26 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 1.88 in | Assembly/Box Mounting: | F1 ONLY |
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Break-Down | 0.00 | 0.0 | 223.20 | 311.0 | 1,514 | 0.00 | 0.0 | 1.50 |
| Locked-Rotor | 60.80 | 779.0 | 223.00 | 311.0 | 0 | 10.90 | 77.9 | 1.50 |
| Pull-Up | 0.00 | 0.0 | 182.00 | 253.0 | 1,236 | 0.00 | 0.0 | 1.50 |
| Full Load | 7.80 | 100.0 | 71.80 | 100.0 | 1,755 | 1.37 | 76.6 | 1.50 |
| % of Rated Load | 0 % | 25 % | 50 % | 75 % | 100 % | 115 % | 125 % | 150 % |
| Current (Amps) | 5.11 | 5.28 | 5.85 | 6.71 | 7.80 | 8.58 | 9.13 | 10.61 |
| Rated Output (KW) | 0.21 | 0.47 | 0.76 | 1.06 | 1.37 | 1.58 | 1.72 | 2.08 |
| Efficiency (%) | 0.0 | 59.4 | 74.2 | 79.6 | 81.4 | 81.8 | 81.6 | 80.7 |
| Power Factor (%) | 17.5 | 38.7 | 56.1 | 68.7 | 76.6 | 80.0 | 81.9 | 85.2 |
| Speed (RPM) | 1,798 | 1,788 | 1,778 | 1,767 | 1,755 | 1,747 | 1,741 | 1,728 |
| Temp. Rise @ FL | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| Torque (ft-lbs) | 0.00 | 17.60 | 35.50 | 53.80 | 71.80 | 83.20 | 90.80 | 109.40 |
