| UPC: | 786674017154 | Weight: | 25 LB |
| Packaged Length: | 16 IN | Packaged Width: | 9.5 IN |
| Packaged Height: | 11 IN |
| Output HP: | 3/4 Hp | Output KW: | 0.56 kW |
| Frequency: | 60 Hz | Voltage: | 230/115 V |
| Current: | 5.5/11.0 A | Speed: | 3450 rpm |
| Service Factor: | 1.5 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56C | Enclosure: | Open Drip Proof |
| Thermal Protection: | Automatic | Ambient Temperature: | 50 °C |
| UL: | Recognized | CSA: | Y |
| Electrical Type: | Capacitor Start Capacitor Run | Poles: | 2 |
| Rotation: | Counterclockwise Pump End | Mounting: | C Face |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 13.75 in |
| Frame Length: | 8.31 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 2.06 in |
